ClearFlex®

ClearFlex® is a light weight and very flexible PVC ducting which can be used for the suction of air, fumes and light dusts. ClearFlex offers excellent flexibility and good compressibility and is supplied in 10m rolls or cut lengths to order.

Light weight and very flexible PVC ducting



Technical Data

Further diameters avaliable upon request. Technical data are based on +20°C

Product Code
(dia)
Wire Thickness
(mm)
Weight
(kg/m)
Bend Radius
(mm)
Max Pressure (bar)
Max Vacuum (bar)
CLEARFLEX025
1.0
0.134
16
0.40
0.20
CLEARFLEX032
1.2
0.171
21
0.40
0.20
CLEARFLEX040
1.2
0.228
28
0.40
0.18
CLEARFLEX045
1.2
0.257
32
0.40
0.18
CLEARFLEX052
1.2
0.285
35
0.35
0.15
CLEARFLEX060
1.2
0.342
42
0.35
0.14
CLEARFLEX063
1.2
0.342
42
0.35
0.14
CLEARFLEX076
1.2
0.427
53
0.30
0.10
CLEARFLEX082
1.2
0.456
56
0.25
0.09
CLEARFLEX090
1.2
0.519
63
0.23
0.09
CLEARFLEX102
1.6
0.581
70
0.20
0.08
CLEARFLEX115
1.6
0.653
79
0.18
0.07
CLEARFLEX127
1.6
0.726
88
0.15
0.06
CLEARFLEX152
1.6
0.871
105
0.08
0.05
CLEARFLEX180
1.6
1.017
123
0.06
0.04
CLEARFLEX203
2.0
1.178
140
0.05
0.03
CLEARFLEX229
2.0
1.326
158
0.05
0.03
CLEARFLEX254
2.0
1.473
175
0.04
0.03
CLEARFLEX305
2.0
1.767
210
0.03
0.02
CLEARFLEX356
2.0
2.062
245
0.02
0.02
CLEARFLEX406
2.0
2.356
280
0.02
0.01
CLEARFLEX425
2.0
2.504
297
0.02
0.01
CLEARFLEX457
2.0
2.651
315
0.01
0.01
CLEARFLEX508
2.0
2.945
350
0.01
0.01

Material
Polyvinyl Chloride (PVC)

Wall Thickness
0.4mm

Colour
Clear

Single Length
10m rolls / cut lengths to order

Temperature Resistance
0°C up to + 70°C

Applications
Suction of air, fumes and light dusts

Properties

  1. Excellent flexibility
  2. Good compressibility
